MCQEasyJEE Main 2026 · 22 January, Shift 1Logic Gates

Find the correct combination of $A$ , $B$ , $C$ and $D$ inputs which can cause the LED to glow.

Logic circuit with inputs A, B, C and D feeding NOR gates, whose outputs connect to an LED on the right side.

A
$0100$
B
$1000$
C
$0011$
D
$1101$
