MCQEasyJEE 2023Magnetic Dipole & Bar Magnet

JEE Physics 2023 Question with Solution

Banner image related to JEE Main 2023 question solutions with National Testing Agency branding and exam paper solutions text.

JEE Main 2023 Questions with Solutions

A bar magnet with a magnetic moment 5.0 A m25.0 \, \text{A m}^2 is placed in parallel position relative to a magnetic field of 0.4 T0.4 \, \text{T}. The amount of required work done in turning the magnet from parallel to antiparallel position relative to the field direction is:

  • A

    4 J4 \, \text{J}

  • B

    1 J1 \, \text{J}

  • C

    2 J2 \, \text{J}

  • D

    Zero

Answer

Correct answer:A

Step-by-step solution

Standard Method

Given: Magnetic moment M=5.0 A m2M = 5.0 \, \text{A m}^2 and magnetic field B=0.4 TB = 0.4 \, \text{T}.

Find: The work required to rotate the bar magnet from parallel to antiparallel position.

The potential energy of a magnetic dipole in a magnetic field is

u=−MBcos⁡θu = -MB\cos\theta

The work done in rotating the dipole is the change in potential energy:

W=ΔuW = \Delta u

Initially, the magnet is parallel to the field, so

θ=0∘\theta = 0^\circ

Finally, it is antiparallel to the field, so

θ=180∘\theta = 180^\circ

Therefore,

W=−MBcos⁡180∘−(−MBcos⁡0∘)W = -MB\cos 180^\circ - \left(-MB\cos 0^\circ\right) W=−MB(−1)−(−MB)(1)W = -MB(-1) - (-MB)(1) W=MB+MB=2MBW = MB + MB = 2MB

Substituting the values,

W=2×5×0.4W = 2 \times 5 \times 0.4 W=4 JW = 4 \, \text{J}

Therefore, the correct option is A.

Energy Change Approach

Given: A magnetic dipole is rotated in a uniform magnetic field from parallel to antiparallel orientation.

Find: The required work done.

Use the magnetic potential energy relation:

u=−MBcos⁡θu = -MB\cos\theta

For the initial parallel position,

ui=−MBcos⁡0∘=−MBu_i = -MB\cos 0^\circ = -MB

For the final antiparallel position,

uf=−MBcos⁡180∘=+MBu_f = -MB\cos 180^\circ = +MB

Hence the change in energy is

Δu=νf−νi\Delta u = \nu_f - \nu_i Δu=MB−(−MB)\Delta u = MB - (-MB) Δu=2MB\Delta u = 2MB

Since the external work done equals the increase in potential energy,

W=2MB=2×5.0×0.4=4 JW = 2MB = 2 \times 5.0 \times 0.4 = 4 \, \text{J}

Therefore, the answer is 4 J4 \, \text{J}.

Common mistakes

  • Using W=MBW = MB instead of W=2MBW = 2MB. This is wrong because the magnet moves from 0∘0^\circ to 180∘180^\circ, so the potential energy changes from −MB-MB to +MB+MB. Always compute final minus initial energy.

  • Confusing torque with work done. Torque depends on sin⁡θ\sin\theta, but the required work here must be found from the change in potential energy. Use u=−MBcos⁡θu = -MB\cos\theta.

  • Taking the final energy at 180∘180^\circ as negative. This is incorrect because cos⁡180∘=−1\cos 180^\circ = -1, hence u=−MB(−1)=+MBu = -MB(-1) = +MB. Evaluate the cosine carefully before substituting.
