Physics Question from JEE Main 2023 · 25 January, Shift 2

Two cells are connected between points A and B as shown. Cell 11 has an emf of 12V12 \, \text{V} and internal resistance of 3Ω3\Omega. Cell 22 has an emf of 6V6 \, \text{V} and internal resistance of 6Ω6\Omega. An external resistor of 4Ω4\Omega is connected across A and B. The current flowing through R will be _____ A.

Circuit between points A and B with two parallel cell branches: top branch has 12 V cell with 3 ohm internal resistance, bottom branch has 6 V cell with 6 ohm internal resistance, and a 4 ohm external resistor connected across A and B.
